The new adapter board for decoders with 21MTC interface is suitable for anyone who wants to digitize their locomotives quickly and without much soldering effort and equip them with many functions. The adapter board, with its compact dimensions of 30.5mm x 15.5mm, is almost as big as the decoder and additionally equipped with a break-off mounting strap. For the functions AUX3 to AUX6, which are implemented on VHDM, NEM or NMRA compliant decoders as logic outputs, power amplifiers (approx. 250mA e

The new adapter board for decoders with PluX22 interface is suitable for anyone who wants to quickly digitize their locomotives and equip them with many functions quickly and without much soldering. The adapter board with the compact dimensions of 32.5mm x 15.5mm is additionally equipped with a break-off fastening strap. All outputs according to VHDM or NEM standard are available as solder connections. Already soldered connection cables with approx. 20 cm length for the most important contacts e

This adapter board provides the appropriate connection of the LokSound L decoder. The decoder is plugged directly into the female connectors. On the output side, the adapter board provides soldering points for all functions of the decoder. The adapter board can be fixed with screws in the model.

Permanent magnet such as 220560, for armature 217450, D = 24.5mm, for motor plates 216730, 211990, 228500 (large disc collector motor). For the conversion of old Märklin® all-electric motors you need a permanent magnet. It replaces the previous field winding and helps your old locomotives in conjunction with a LokSound or LokPilot decoder to a driving behavior that you would never have expected the locomotives! In total, there are four different magnets, which is needed exactly depends on the an

Permanent magnet such as 220450, for Anker 200680, D = 18.0mm, for engine plate 204900 (small disc collector motor). For the conversion of old Märklin® all-electric motors you need a permanent magnet. It replaces the previous field winding and helps your old locomotives in conjunction with a LokSound or LokPilot decoder to a driving behavior that you would never have expected the locomotives! In total, there are four different magnets, which is needed exactly depends on the anchor type. The numb

Permanent magnet like 235690 and 245480, for armature 231440, D = 19,1mm, for motor plate 231350 (drum collector motor). For the conversion of old Märklin® all-electric motors you need a permanent magnet. It replaces the previous field winding and helps your old locomotives in conjunction with a LokSound or LokPilot decoder to a driving behavior that you would never have expected the locomotives! In total, there are four different magnets, which is needed exactly depends on the anchor type. The

1 amp miniature switching relay, 16 volts. With the small switching relay loads can be switched, which require more power than a function output of the decoder can afford. In this case, simply switch the relay in between. If you want to use a smoke generator, you also need the relay, so that it can work properly.

Permanent magnet, for Märklin® 3015, ET800, ST800, Spur 1 all-electric motors. For the conversion of old Märklin® all-electric motors you need a permanent magnet. It replaces the previous field winding and helps your old locomotives in conjunction with a LokSound or LokPilot decoder to a handling that you would never have expected the locomotive! In total, there are four different magnets, which is needed exactly depends on the anchor type. The number of the anchor can be found in the spare part

Many railcars are provided at both ends with a grinder. For proper function in block locations and for timely stopping in front of red signals, it is essential that only one grinder is used to power the decoder, depending on the direction of travel. This is ensured by the slider changeover. It is hung between the pantographs and a LokPilot or LokSound decoder with 21MTC interface. These generate a control signal that evaluates the wiper switching electronics and switches the "right" wiper. This

The 21MTC adapter board is suitable if you want to digitize a locomotive without an interface, but do not want to freely wire the decoder. The adapter board provides a recording option for decoders with 21MTC interface. This decoder is simply plugged. On the other hand, 21 pads allow a clean wiring of your locomotive. This adapter board allows you to perform a clean conversion and take advantage of the additional features of the 21MTC interface (such as speaker outputs). Dimensions: Length 22.0m

The 21MTC adapter board is suitable if you want to digitize a locomotive without an interface, but do not want to freely wire the decoder or use more than 4 function outputs on your LokPilot or LokSound decoder. This adapter board mimics the typical design of the Märklin® 6090x decoder and can be installed wherever this place would be. The decoder with 21MTC interface is simply plugged onto the board. On the output side, this adapter already offers soldered cables (approx. 20 cm in length) for a

With this expansion board you can elegantly extend your LokPilot V4.0 or LokSound V4.0 decoder (with 21MTC interface!): Simply plug the decoder onto the device and use 8 additional function outputs (AUX3 to AUX10) for lighting effects, coupling etc. You can also connect 4 RC servos. The necessary 5V voltage is also provided. The highlight of the module is the control electronics for clocked smoke generators: Simply install an ESU smoke generator (from the BR 215) in your locomotive and let it ge

For the professionals among digital converters, the adapter board is intended. This makes the installation easier and safer for us. First, all connections are made to the solder pads of the adapter board instead of the decoder. For this purpose, all signals are multiple and present on the top and bottom. Then the LokSound XL V4.0 decoder with pin header is simply plugged onto the board. Finished. Finally, you can easily remove and replace the decoder at any time.

The steam smoke distillate produces a realistic dense, white vapor and evaporates residue-free, without the usual traces in the smoke generator, on locomotives, building roofs or plant surfaces. It is also easy to wipe off with alcohol and will not affect the finish or aging of your models.

This adapter board can be docked to all decoders with an E24 connection and offers a PluX16 interface on the locomotive side. This means that, for example, a LokSound 5 Nano or LokPilot 5 Nano can be easily installed in older locomotives that only have a PluX16 interface (e.g. some Fleischmann H0 locomotives or Piko N or TT locomotives).

Adapter cable, 18-pol. Next18 female to open strands, 88mm, with heat shrink tubing.

Adapter board, 18-pin Next-18 female to NEM651 6-pin, Flex, 88mm, with heat shrink tubing.

Adapter board, 18-pin Next-18 female to NEM652 8-pin, Flex, 88mm, with heat shrink tubing.

Adapter board Next-18 to NEM 658 16-pin PluX16.

ESU 51997 – Adapter board, 18-pin Next-18 socket to PluX12, Flex, 88mm

ESU 51998 – Adapter board 21MTC to Next18, for certain Liliput engines

ESU 51999 – Adapter board Next18 for 6 amplified outputs. With soldering pads and wires
